Features

Title 2021 LOVOL M504 TB
Make LOVOL
Price $27,000
Listing Type New
Stock Number S36
RefCode TA1100448
Drive TypeFWA
FELYES
Number Cylinders/cc4
Usage Hours0

Description

Lovol M504, 50hp Gen II Tractor with 4in1 Front end Loader



Built Simple - Built Tough this budget tractor doesn't have all the features of its bigger brother but its still boasting the strong drive line and large front axle that Lovol engineers use in their TB Series tractors.

Key Features
10 inch Ceramic plate clutch
8x8 Gearbox
Shuttle Shift
4wd & Diff Lock
Quiet Exhaust
14.9 AG Tyres
3 Year Warranty
600kg SWL Front end Loader
4in1 Euro Mount Quick Hitch Bucket
Gen II Design with Quality Finishes
Genuine LOVOL Tractor
TRACTOR DETAILS

Model


M604 Rops

Engine Gross Power

HP(kw)

50(36.8)

Rated Revolution

rpm

2400

PTO HorsePower

HP(kw)

42 (31)

Type


natural

No.of Cylinders


4

Total Displace

cc

4087

Bore&stroke

mm


Combustion System


DI

Battery

Ah/h

100

Cooling System


Coolant/Water

Capacity

Fuel Tank

L

60

Engine Crankcase(Included Filter)

L

9

Engine Coolant

L

8.75

Transmission Case

L

27

Support of Front Axle

L

7

PTO

Maximum PTO Power

HP

50

Rear PTO


6 Spline

Type


dual speed

Revolution

rpm

540/540E (760)

Hydraulic

Steering


hydraulic

3 Point Lift Control Type


draft/position

Implement Pump

L/min

30

Power Steering Pump

L/min

13

Total Hydraulic Flow

L/min

43

3-point Hitch Type


cat I

Lower Link Type


hinge

Check Link Type


lever

Top Link Type


hinge

Lift rod type


thread

Lift capacity at lift point

KN

2,294 kgf

Lift capacity at 24 in.behind lift point

KN

1,428 kgf

Drawbar type


swing

Max. Trailer Loading Weight

kg

6000

No.of Standard Remote Valve's Ports (Rear)


2 Sets

Towing Capacity (based on 7.5km/h)

Maximum Towing Power

KN

>13.2

Drive Train

Transmission



Main Gear Shift x Range Gear Shift


4x2 range

No. of Speeds


F8+R8

Shuttle Type


mechanical shuttle

Brake Type


wet/double disc per side

Main Clutch Type


Dry with Springs

Main Clutch Diameter

mm

254mm / 11 Inch or 10inch

Mechanical Differential Lock


yes

Front Wheel Drive System


4WD

Traveling Speeds

Forward

km/h

2.37-38.46

Reverse

km/h

2.07-33.71

Dimensions

Overall Length (With 3 Point & front Weight)

mm

4136

Overall Width(Minimum Tread)

mm

1870

Tread Width Front 4wd

mm

1250

Tread Width Rear

mm

1300

Overall Height(With ROPS)

mm

2657

Wheel Base

mm

1990

Ground(Crop) Clearance

mm

310

Turning Radius(w/brake)

mm

4300/3800

Weight with ROPS Without Loader

kg

2320

Tyre Size

Front


8.3-20 AG

Rear


14.9-24 AG

Specs are correct at time of posting but subject to change..



Optional 5ft slasher shown in some photos
